Synology DiskStation DS423+ שרת סינולוג'י 4 מפרצים ללא דיסקים

שלוש שנות אחריות מעבדת היבואן

Synology DiskStation DS423+ 4Bay A compact storage hub with 100% data ownership



מפרט טכני מלא

CPU

CPU ModelIntel Celeron J4125CPU Quantity1CPU Core4CPU Architecture64-bitCPU Frequency2.0 (base) / 2.7 (turbo) GHzHardware Encryption Engine

Memory

System Memory2 GB DDR4 non-ECCTotal Memory Slots1Maximum Memory Capacity6 GB (2 GB + 4 GB)Notes

• Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
• Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.

Storage

Drive Bays4M.2 Drive Slots2 (NVMe)Compatible Drive Type* (See all supported drives)

• 3.5" SATA HDD
• 2.5" SATA SSD
• M.2 2280 NVMe SSD

Hot Swappable Drive*Notes

• The hot swappable drive feature is not supported by M.2 SSD slots.
• "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.

External Ports

RJ-45 1GbE LAN Port2USB 3.2 Gen 1 Port*2Notes

• This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
• The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.

Appearance

Size (Height x Width x Depth)166 mm x 199 mm x 223 mmWeight2.18 kg

Others

System Fan92 mm x 92 mm x 2 pcsFan Speed Mode

• Full-Speed Mode
• Cool Mode
• Quiet Mode

Brightness Adjustable Front LED IndicatorsPower RecoveryNoise Level*19.8 dB(A)Scheduled Power On / OffWake on LAN / WANPower Supply Unit / Adapter90 wattsAC Input Power Voltage100V to 240V ACPower Frequency50/60 Hz, Single PhasePower Consumption28.3 watts (Access)
8.45 watts (HDD Hibernation)British Thermal Unit96.5 BTU/hr (Access)
28.81 BTU/hr (HDD Hibernation)Notes

• Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle stae. Two G.R.A.S. Type 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%

Temperature

Operating Temperature0°C to 40°C (32°F to 104°F)Storage Temperature-20°C to 60°C (-5°F to 140°F)Relative Humidity5% to 95% RH

Certification

• FCC
• CE
• BSMI
• VCCI
• RCM
• UKCA
• EAC
• CCC
• KC

Environment

RoHS Compliant

Packaging Content

• Main Unit X 1
• Accessory Pack X 1
• AC Power Adapter X 1
• AC Power Cord X 1
• RJ-45 LAN Cable X 2
• Quick Installation Guide X 1

Optional Accessories

• DDR4 non-ECC SODIMM: D4NESO-2666-4G
• Enterprise Series 3.5" SATA HDD: HAT5300 Series
• Plus Series 3.5" SATA HDD: HAT3300 Series
• Enterprise Series 2.5" SATA SSD: SAT5200 Series
• Enterprise Series M.2 2280 NVMe SSD: SNV3400 Series

NotesAll memory modules will operate at the maximum frequency specified by the CPU manufacturer.
